Bit06 Digital input 7 (via ADC 1) 0 OFF, 1 ON
Bit07 Digital input 8 (via ADC 2) 0 OFF, 1 ON
Note:
Segment is lit when signal is active
P0725 PNP / NPN digital inputs
Switches between active high (PNP) and active low (NPN). This is valid for all digital inputs
simultaneously.
Unit: - Min: 0 Def: 1 Max: 1
Level 3
Settings:
0=NPN mode ==> low active 1=PNP mode ==> high active
P0731[2] BI: Function of digital output 1
Defines source of digital output 1
Unit: - Min: 0.0 Def: 52.3 Max: 4000.0
Level 2
Settings:
52.0 VSD ready 0 Closed
52.1 VSD ready to run 0 Closed
52.2 VSD running 0 Closed
52.3 VSD fault active 0 Closed
52.4 OFF2 active 1 Closed
52.5 OFF3 active 1 Closed
52.6 Switch on inhibit active 0 Closed
52.7 VSD warning active 0 Closed
52.8 Deviation setpoint/actual value 1 Closed
52.9 PZD control (Process Data Control) 0 Closed
52.A Maximum frequency reached 0 Closed
52.B Warning: Motor current limit 1 Closed
52.C Motor holding brake (MHB) active 0 Closed
52.D Motor overload 1 Closed
52.E Motor running direction right 0 Closed
52.F VSD VSD overload 1 Closed
53.0 DC brake active 0 Closed
53.1 VSD frequency less switch off limit 0 Closed
53.2 VSD frequency less minimum freq. 0 Closed
53.3 Current greater or equal than limit 0 Closed
53.4 Act. freq. greater comparison freq. 0 Closed
53.5 Act. freq. less comparison freq. 0 Closed
53.6 Act. freq. greater/equal setpoint 0 Closed
53.7 Voltage less than threshold 0 Closed
53.8 Voltage greater than threshold 0 Closed
53.A PID output at lower limit (P2292) 0 Closed
53.B PID output at upper limit (P2291) 0 Closed
Index:
P0731[0]: VSD in Auto mode P0731[1]: VSD in Hand mode
P0732[2] BI: Function of digital output 2
Defines source of digital output 2
Unit: -
Min: 0.0
Def: 52.2 Max: 4000.0
Level 2
Details:
See P0731 (function of digital output 1)
r0747 CO/BO: State of digital outputs
Displays state of digital outputs (also includes inversion of digital outputs via P0748)
Unit: - Min: - Def: - Max: -
Level 3
Bit fields:
Bit00 Digital output 1 energized 0 NO, 1 YES
Bit01 Digital output 2 energized 0 NO, 1 YES
Dependency:
Bit 0= Relay deenergized / contacts open
Bit 1= Relay energized / contacts closed
P0748 Invert digital outputs
Defines high and low states of relay for a given function
Unit: - Min: 0 Def: 0 Max: 7
Level 3
Bit fields:
Bit00 Invert digital output 1 0 NO, 1 YES
Bit01 Invert digital output 2 0 NO, 1 YES
r0752[2] Act. input of ADC [V] or [mA]
Displays smoothed analog input value in Volts before the characteristic block
Unit: - Min: - Def: - Max: -
Level 2
Index:
r0752[0]: Analog input 1 (ADC 1) r0752[1]: Analog input 2 (ADC 2)
P0753[2] Smooth time ADC
Defines filter time (PT1 filter) in [ms] for analog input
Unit: ms Min: 0 Def: 100 Max: 10000
Level 3
Index:
P0753[0]: Analog input 1 (ADC 1) P0753[1]: Analog input 2 (ADC
Note:
Increasing this time (smooth) reduces jitter but slows down response to the analog input
r0754[2] Act. ADC value after scaling [%]
Shows smoothed value of analog input in [%] after scaling block
Unit: % Min: - Def: - Max: -
Level 2
Index:
r0754[0]: Analog input 1 (ADC 1) r0754[1]: Analog input 2 (ADC 2)
Dependency:
P0757 to P0760 define range (ADC scaling)
r0755[2] CO: Act. ADC after scaling [4000h]
Displays analog input, scaled using ASPmin and ASPmax.
Unit: - Min: - Def: - Max: -
Level 3
Data:
The analog setpoint (ASP) from the analog scaling block can vary from min. analog setpoint (ASPmin) to a max. analog
setpoint (ASPmax) as shown in P0757 (ADC scaling).
The largest magnitude (value without sign) of ASPmin and ASPmax defines the scaling of 16384
Example:
ASPmin=300 %, ASPmax=100 %, then 16384 represents 300 %
This parameter will vary from 5461 to 16364
ASPmin=-200 %, ASPmax=100 % then 16384 represents 200 %
This parameter will vary from –16384 to +8192
Index:
r0755[0]: Analog input 1 (ADC 1) r0755[1]: Analog input 2 (ADC 2)
Note:
This value is used as an input to analog BICO connectors
ASPmax represents the highest analog setpoint (this may be at 10 V)
ASPmin represents the lowest analog setpoint (this may be at 0 V)
Details:
See parameters P0757 to P0760 (ADC scaling)
