Siemens Building Technologies Commissioning Guide CM1G5192en
HVAC Products 10 Parameterization 26.02.2003
Bit12 Motor holding brake active 0 NO, 1 YES
Bit13 Motor overload 0 YES, 1 NO
Bit14 Motor runs direction right 0 NO, 1 YES
Bit15 VSD VSD overload 0 YES, 1 NO
P0970 Factory reset
P0970 = 1 resets all parameters to their default values
Unit: - Min: 0 Def: 0 Max: 1
Level 1
Settings:
0=Disabled 1=Parameter reset
Dependency:
First set P0010=30 (factory settings)
Stop VSD (i.e. disable all pulses) before you can reset parameters to default values
Note:
The following parameters retain their values after a factory reset:
P0918 (CB address),
P2010 (USS baud rate) and
P2011 (USS address)
P0971 Transfer data from RAM to EEPROM
Transfers values from RAM to EEPROM when set to 1
Unit: - Min: 0 Def: 0 Max: 1
Level 3
Settings:
0=Disabled 1=Start transfer
Note:
All values in RAM are transferred to EEPROM
Parameter is automatically reset to 0 (default) after successful transfer
P1000[2] Selection of frequency setpoint
Selects frequency setpoint source. In the table of possible settings below, the main setpoint is
selected from the least significant digit (i.e., 0 to 6) and any additional setpoint from the most
significant digit (i.e., x0 through x6)
Unit: - Min: 0 Def: 2 Max: 77
Level 1
Data:
Selects frequency setpoint source. In the table of possible settings below, the main setpoint is selected from the least
significant digit (i.e., 0 to 6) and any additional setpoint from the most significant digit (i.e., x0 through x6)
Example:
Setting 12 selects main setpoint (2) derived from analog input with additional setpoint (1) taken from the motor potentiometer
Settings:
0=No main setpoint
1= Motor potentiometer (MOP) setpoint
2=Analog setpoint
3=Fixed frequency
4=USS on BOP link
5=USS on COM link
6= Communication board (CB) on COM link
7=Analog setpoint 2
10=No main setpoint + MOP setpoint
11=MOP setpoint + MOP setpoint
12=Analog setpoint + MOP setpoint
13=Fixed frequency + MOP setpoint
14=USS on BOP link + MOP setpoint
15=USS on COM link + MOP setpoint
16=CB on COM link + MOP setpoint
17=Analog setpoint 2 + MOP setpoint
20=No main setpoint + Analog setpoint
21=MOP setpoint + Analog setpoint
22=Analog setpoint + Analog setpoint
23=Fixed frequency + Analog setpoint
24=USS on BOP link + Analog setpoint
25=USS on COM link + Analog setpoint
26=CB on COM link + Analog setpoint
27=Analog setpoint 2 + Analog setpoint
30=No main setpoint + Fixed frequency
31=MOP setpoint + Fixed frequency
32=Analog setpoint + Fixed frequency
33=Fixed frequency + Fixed frequency
34=USS on BOP link + Fixed frequency
35=USS on COM link + Fixed frequency
36=CB on COM link + Fixed frequency
37=Analog setpoint 2 + Fixed frequency
40=No main setpoint + USS on BOP link
41=MOP setpoint + USS on BOP link
42=Analog setpoint + USS on BOP link
43=Fixed frequency + USS on BOP link
44=USS on BOP link + USS on BOP link
45=USS on COM link + USS on BOP link
46=CB on COM link + USS on BOP link
47=Analog setpoint 2 + USS on BOP link
50=No main setpoint + USS on COM link
51=MOP setpoint + USS on COM link
52=Analog setpoint + USS on COM link
53=Fixed frequency + USS on COM link
54=USS on BOP link + USS on COM link
55=USS on COM link + USS on COM link
56=CB on COM link + USS on COM link
57=Analog setpoint 2 + USS on COM link
60=No main setpoint + CB on COM link
61=MOP setpoint + CB on COM link
62=Analog setpoint + CB on COM link
63=Fixed frequency + CB on COM link
64=USS on BOP link + CB on COM link
65=USS on COM link + CB on COM link
66=CB on COM link + CB on COM link
67=Analog setpoint 2 + CB on COM link
70=No main setpoint + Analog setpoint 2
71=MOP setpoint + Analog setpoint 2
72=Analog setpoint + Analog setpoint 2
73=Fixed frequency + Analog setpoint 2
74=USS on BOP link + Analog setpoint 2
75=USS on COM link + Analog setpoint 2
76=CB on COM link + Analog setpoint 2
77=Analog setpoint 2 + Analog setpoint 2
Index:
P1000[0]: VSD in Auto Mode Operation
P1000[1]: VSD in Hand Mode Operation
Note:
Single digits denote main setpoints that have no additional setpoint
P1001 Fixed frequency 1
Defines fixed frequency setpoint 1
Unit: Hz Min: -650.0 Def: 0.00 Max: 650.00
Level 3
Data:
There are 3 types of fixed frequencies:
1. Direct selection (P0701 - P0706=15)
In this mode of operation 1 digital input selects 1 fixed frequency. If several inputs are active together, the selected
frequencies are summed, e.g., FF1 + FF2 + FF3 + FF4 + FF5 + FF6
2. Direct selection + ON command (P0701 - P0706=16)
The fixed frequency selection combines the fixed frequencies with an ON command. In this mode of operation 1,
digital input selects 1 fixed frequency. If several inputs are active together, the selected frequencies are summed,
e.g., FF1 + FF2 + FF3 + FF4 + FF5 + FF6
3. Binary coded selection + ON command (P0701 - P0706=17)
Select up to 16 fixed frequencies using this method. Select the fixed frequencies according to the following table:
