Siemens Building Technologies Commissioning Guide CM1G5192en
HVAC Products 10 Parameterization 26.02.2003
DIN4 DIN3 DIN2 DIN1
OFF Inactive Inactive Inactive Inactive
P1001 FF1 Inactive Inactive Inactive
Active
P1002 FF2 Inactive Inactive
Active
Inactive
P1003 FF3 Inactive Inactive
Active Active
P1004 FF4 Inactive
Active
Inactive Inactive
P1005 FF5 Inactive
Active
Inactive
Active
P1006 FF6 Inactive
Active Active
Inactive
P1007 FF7 Inactive
Active Active Active
P1008 FF8
Active
Inactive Inactive Inactive
P1009 FF9
Active
Inactive Inactive
Active
P1010 FF10
Active
Inactive
Active
Inactive
P1011 FF11
Active
Inactive
Active Active
P1012 FF12
Active Active
Inactive Inactive
P1013 FF13
Active Active
Inactive
Active
P1014 FF14
Active Active Active Active
P1015 FF15
Active Active Active Active
Dependency:
Select fixed frequency operation (using P1000)
VSD requires ON command to start in the case of direct selection (P0701 to P0706=15)
Note:
Fixed frequencies can be selected using the digital inputs, and can also be combined with an ON command
P1002-P1015 Fixed frequency 2 through 15
Defines fixed frequency setpoint 2
Unit: Hz Min: -650.00 Def: See Note below Max: 650.00
Level 3
Details:
See P1001 (fixed frequency 1)
Default fixed frequency setpoint values are as follows:
Fixed frequency Default Fixed frequency Default Fixed frequency Default
1 0.00 6 25.00 11 50.00
2 5.00 7 30.00 12 55.00
3 10.00 8 35.00 13 60.00
4 15.00 9 40.00 14 65.00
Note:
5 20.00 10 45.00 15 65.00
P1016 to
P1019
Fixed frequency mode - Bit 0 through 3
Fixed frequencies can be selected in 3 different modes. Parameter P1016 defines the mode of
selection Bit 0.
Unit: - Min: 1 Def: 1 Max: 3
Level 3
Details:
Parameter P1016 defines the mode of Bit 0, parameter P1017 defines the mode of Bit 1, parameter P1018 defines the
mode of Bit 2, and parameter P1019 defines the mode of Bit 3
Settings:
1=Direct selection 2=Direct selection + ON command 3=Binary coded selection + ON command
Note:
See table in P1001 (fixed frequency 1) for a description of how to use fixed frequencies
P1020[2] to
P1023[2]
BI: Fixed frequency selection Bit 0
Defines origin of fixed frequency selection
Unit: - Min: 0:0 Def: 0:0 (P1023 = 722:3) Max: 4000:0
Level 3
Settings:
P1020= 722.0 ==> Digital input 1
P1021= 722.1 ==> Digital input 2
P1022= 722.2 ==> Digital input 3
P1023= 722.3 ==> Digital input 4
P1026= 722.4 ==> Digital input 5
P1028= 722.5 ==> Digital input 6
Index:
P1020[0]: VSD in Auto mode for Bit 0
P1021[0]: VSD in Auto mode for Bit 1
P1022[0]: VSD in Auto mode for Bit 2
P1023[0]: VSD in Auto mode for Bit 3
P1020[1]: VSD in Hand mode for Bit 0
P1021[1]: VSD in Hand mode for Bit 1
P1022[1]: VSD in Hand mode for Bit 2
P1023[1]: VSD in Hand mode for Bit 3
Dependency:
Accessible only if P0701 - P0706=99 (function of digital inputs=BICO)
r1024 CO: Act. fixed frequency Level 3
Displays sum total of selected fixed frequencies
Unit: Hz Min: - Def: - Max: -
P1025 Fixed frequency mode - Bit 4
Direct selection or direct selection + ON for bit 4
Unit: - Min: 1 Def: 1 Max: 2
Level 3
Settings:
1=Direct selection 2=Direct selection + ON command 3=Binary coded selection + ON command
Details:
See parameter P1001 for description of how to use fixed frequencies
P1026[2] BI: Fixed frequency selection Bit 4
Defines origin of fixed frequency selection
Unit: - Min: 0:0 Def: 722:4 Max: 4000:0
Level 3
Index:
P1026[0]: VSD in Auto mode P1026[1]: VSD in Hand mode
Dependency:
Accessible only if P0701 - P0706=99 (function of digital inputs=BICO)
Details:
See P1020 (fixed frequency selection Bit 0) for most common settings
P1027 Fixed frequency mode - Bit 5
Direct selection or direct selection + ON for bit 5
Unit: - Min: 1 Def: 1 Max: 2
Level 3
Settings:
1=Direct selection 2=Direct selection + ON command 3=Binary coded selection + ON command
Details:
See parameter P1001 for description of how to use fixed frequencies
