Siemens SED2 Commissioning Manual

75/80
Siemens Building Technologies Commissioning Guide CM1G5192en
HVAC Products 10 Parameterization 26.02.2003
Note:
When setting 1 is selected, only the parameter settings carried out via the commissioning menu "Quick commissioning"
are retained. All other parameter changes, including the I/O settings, are lost. Motor calculations are also performed.
When setting 2 is selected, only the parameters that depend on the parameters in the commissioning menu "Quick
commissioning" (P0010=1) are calculated. The I/O settings are also reset to default and the motor calculations per-
formed.
When setting 3 is selected, only the motor and controller calculations are performed. Exiting quick commissioning with
this setting saves time (for example, if only motor rating plate data have been changed).
Calculates a variety of motor parameters, overwriting previous values. These include P0344 (level 3, motor weight),
P0350 (level 3, demagnetization time), P2000 (reference frequency), P2002 (level 3, reference current).

Siemens SED2 Specifications

General

Input Voltage	380-480V AC
Current Rating	Depends on model
Control Type	Digital
Communication	PROFIBUS, PROFINET, Ethernet
Communication Interface	RS485
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Operating Temperature	0 to +45 °C
Storage Temperature	+70 °C
