Siemens SED2 Commissioning Guide

21 / 100
Siemens Commissioning Guide CM1G5192en
Building Technologies 5 Electrical installation 29.07.2010
5.2.3 Access to the connection terminals: Frame sizes D…F IP20
Removing the operator
panel (BOP or AOP)
Opening the housing:
Frame sizes D and E
3
1
2
5
6
4
5
1
9
2
J
1
3
Opening the housing:
Frame size F
2
3
4
1
5
1
9
2
J
1
4
5
6

Siemens SED2 Specifications

General

Input Voltage	380-480V AC
Current Rating	Depends on model
Control Type	Digital
Communication	PROFIBUS, PROFINET, Ethernet
Communication Interface	RS485
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Operating Temperature	0 to +45 °C
Storage Temperature	+70 °C
