Siemens Commissioning Guide CM1G5192en
Building Technologies 10 Parameterization 29.07.2010
P0610 Motor I
2
t temperature reaction
Defines reaction when motor temperature reaches warning threshold.
Unit: - Min: 0 Def: 2 Max: 2
Level 3
Settings: 0=No reaction, warning only 1=Warning and Imax reduction
(results in reduced output freq.)
2=Warning and trip F0011
P0640 Motor overload factor [%]
Defines reaction when motor temperature reaches warning threshold.
Unit: % Min: 10.0 Def: 110.0 Max: 400.0
Level 3
Dependency: Limited to maximum VSD current or to 400% of rated motor current (P0305), whichever is lower.
P0700[2] Selection of command source
Selects digital command source.
Unit: - Min: 0 Def: 2 Max: 6
Level 1
Settings: 0=Factory default setting
1=BOP (keypad)
2=Terminal
4=USS on BOP link
5=USS on COM link
6=CB on COM link
Index: P0700[0]: VSD in ”Auto” mode P0700[1]: VSD in ”Hand” mode
Note: Changing this parameter resets (to default) all settings on item selected. For example: Changing form 1 to 2 resets all
digital inputs to default settings.
P0701[2] Function of digital input 1
Selects function of digital input 1.
Unit: - Min: 0 Def: 1 Max: 99
Level 2
Settings: 0=Digital input disabled
1=ON/OFF1
2=ON reverse /OFF1
3=OFF2 – coast to standstill
4=OFF3 – quick ramp-down
9=Fault acknowledge
10=JOG right
11=JOG left
12=Reverse
13=MOP up (increase freq.)
14=MOP down (decrease freq.)
15=Fixed setpoint (direct selection)
16=Fixed setpoint (direct selection + ON)
17=Fixed setpoint (binary coded selection+ON)
25=DC brake enable
26=Enable essential service
27=Enable PID
28=Bypass mode command input
29=External trip
33=Disable additional freq setpoint
99=Enable BICO parameterization
Index: P0701[0]: VSD in ”Auto” mode P0701[1]: VSD in ”Hand” mode
Dependency: Setting 99 (enable BICO parameterization) requires P0700 (command source) or P3900 (end of quick
commissioning)=1, 2 or P0970 (factory reset)=1 in order to reset.
Note: Setting 99 (BICO) for expert use only.
P0702[2] Function of digital input 2 Level 2
Selects function of digital input 2.
Unit: - Min: 0 Def: 12 Max: 99
Detail: See P0701 (function of digital input1).
P0703[2] Function of digital input 3 Level 2
Selects function of digital input 3.
Unit: - Min: 0 Def: 9 Max: 99
Detail: See P0701 (function of digital input1).
P0704[2] Function of digital input 4 Level 2
Selects function of digital input 4.
Unit: - Min: 0 Def: 15 Max: 99
Detail: See P0701 (function of digital input1).
P0705[2] Function of digital input 5 Level 2
Selects function of digital input 5 (via analog input).
Unit: - Min: 0 Def: 15 Max: 99
Detail: See P0701 (function of digital input1).
Note: Setting 17 is not supported.
P0706[2] Function of digital input 6 Level 2
Selects function of digital input 6 (via analog input).
Unit: - Min: 0 Def: 15 Max: 99
Detail: See P0701 (function of digital input1).
Note: Setting 17 is not supported.
P0707[2] Function of digital input 7
Selects function of digital input 7 (via analog input).
Unit: - Min: 0 Def: 0 Max: 99
Level 3
Settings: 0=Digital input disabled
1=ON/OFF1
2=ON reverse /OFF1
3=OFF2 – coast to standstill
4=OFF3 – quick ramp-down
9=Fault acknowledge
10=JOG right
11=JOG left
12=Reverse
13=MOP up (increase freq.)
14=MOP down (decrease freq.)
25=DC brake enable
26=Enable essential service
29=External trip
33=Disable additional freq. setpoint
99=Enable BICO parameterization
Index: P0707[0]: VSD in ”Auto” mode P0707[1]: VSD in ”Hand” mode
Dependency: Signals about 4 V are active, signals below 1.6 V are inactive.
Note: Signals above 4 V are active, signals below 1.6 V are inactive.
P0708[2] Function of digital input 8
Selects function of digital input 8 (via analog input).
Unit: - Min: 0 Def: 0 Max: 99
Level 3
Detail: See P0707 (function of digital input7).
