Siemens SED2

78 / 100
Siemens Commissioning Guide CM1G5192en
Building Technologies 10 Parameterization 29.07.2010
36=CB on COM link + Fixed frequency
37=Analog setpoint 2 + Fixed frequency
76=CB on COM link + Analog setpoint 2
77=Analog setpoint 2 + Analog setpoint 2
Index: P1000[0]: VSD in ”Auto” mode.
P1000[1]: VSD in ”Hand” mode.
Note: Single digits denote main setpoints that have no additional setpoint.
P1001 Fixed frequency 1
Defines fixed frequency setpoint 1.
Unit: Hz Min: -650.0 Def: 0.00 Max: 650.00
Level 3
Data: There are 3 types of fixed frequencies:
1. Direct selection (P0701 - P0706=15)
In this mode of operation 1 digital input selects 1 fixed frequency. If several inputs are active together, the selected
frequencies are summed, r1024 = FF1 + FF2 + FF3 + FF4 + FF5 + FF6
2. Direct selection + ON command (P0701 - P0706=16)
The fixed frequency selection combines the fixed frequencies with an ON command. In this mode of operation 1,
digital input selects 1 fixed frequency. If several inputs are active together, the selected frequencies are summed.
r1024 = FF1 + FF2 + FF3 + FF4 + FF5 + FF6
3. Binary coded selection + ON command (P0701 - P0704=17)
Select up to 16 fixed frequencies using this method. Select the fixed frequencies (FF1-FF15 via the digital inputs
DIN1 – DIN4) according to the following table:
Note: An ON command is only generated if all 4 digital inputs (P0701 - P0704) are set to 17.
DIN4 DIN3 DIN2 DIN1
OFF Inactive Inactive Inactive Inactive
P1001 FF1 Inactive Inactive Inactive Active
P1002 FF2 Inactive Inactive Active Inactive
P1003 FF3 Inactive Inactive Active Active
P1004 FF4 Inactive Active Inactive Inactive
P1005 FF5 Inactive Active Inactive Active
P1006 FF6 Inactive Active Active Inactive
P1007 FF7 Inactive Active Active Active
P1008 FF8 Active Inactive Inactive Inactive
P1009 FF9 Active Inactive Inactive Active
P1010 FF10 Active Inactive Active Inactive
P1011 FF11 Active Inactive Active Active
P1012 FF12 Active Active Inactive Inactive
P1013 FF13 Active Active Inactive Active
P1014 FF14 Active Active Active Active
P1015 FF15 Active Active Active Active
Dependency: Select fixed frequency operation (using P1000).
VSD requires ON command to start in the case of direct selection (P0701 to P0706=15).
Note: Fixed frequencies can be selected using the digital inputs, and can also be combined with an ON command.
P1002-P1015 Fixed frequency 2 through 15
Defines fixed frequency setpoint 2.
Unit: Hz Min: -650.00 Def: See Note below Max: 650.00
Level 3
Details: See P1001 (fixed frequency 1)
Default fixed frequency setpoint values are as follows:
Fixed frequency Default Fixed frequency Default Fixed frequency Default
1 0.00 6 25.00 11 50.00
2 5.00 7 30.00 12 55.00
3 10.00 8 35.00 13 60.00
4 15.00 9 40.00 14 65.00
Note:
5 20.00 10 45.00 15 65.00
P1016 to
P1019
Fixed frequency mode – Bit 0 through 3
Fixed frequencies can be selected in 3 different modes. Parameter P1016 defines the mode of
selection Bit 0.
Unit: - Min: 1 Def: 1 Max: 3
Level 3
Details: Parameter P1016 defines the mode of Bit 0, parameter P1017 defines the mode of Bit 1, parameter P1018 defines the
mode of Bit 2, and parameter P1019 defines the mode of Bit 3.
Settings: 1=Direct selection 2=Direct selection + ON command 3=Binary coded selection + ON command
Note: See table in P1001 (fixed frequency 1) for a description of how to use fixed frequencies.
P1020[2] to
P1023[2]
BI: Fixed frequency selection Bit 0
Defines origin of fixed frequency selection.
Unit: - Min: 0:0 Def: 0:0 (P1023 = 722:3) Max: 4000:0
Level 3
Settings: P1020=722.0 ==> Digital input 1
P1021=722.1 ==> Digital input 2
P1022=722.2 ==> Digital input 3
P1023=722.3 ==> Digital input 4
P1026=722.4 ==> Digital input 5
P1028=722.5 ==> Digital input 6
Index: P1020[0]: VSD in ”Auto” mode for Bit 0
P1021[0]: VSD in ”Auto” mode for Bit 1
P1022[0]: VSD in ”Auto” mode for Bit 2
P1023[0]: VSD in ”Auto” mode for Bit 3
P1020[1]: VSD in ”Hand” mode for Bit 0
P1021[1]: VSD in ”Hand” mode for Bit 1
P1022[1]: VSD in ”Hand” mode for Bit 2
P1023[1]: VSD in ”Hand” mode for Bit 3
Dependency: Accessible only if P0701 - P0706=99 (function of digital inputs=BICO).
