Siemens SED2

85 / 100
Siemens Commissioning Guide CM1G5192en
Building Technologies 10 Parameterization 29.07.2010
1. "With parameter change" means that the value is actually adopted as the P0350 parameter setting and applied to the
control as well as being shown in the read-only parameters below
2. "Without parameter change" means that the value is only displayed, i.e. shown for checking purposes in the read-
only parameter r1912 (identified stator resistance). The value is not applied to the control
r1912[3] Identified stator resistance
Displays measured stator resistance value (line to line) in [Ohm].
Unit: Ohm Min: - Def: - Max: -
Level 3
Index: r1912[0]: U phase r1912[1]: V phase r1912[2]: W phase
Note: This value is measured using P1910=1 or 2 , i.e., identification of all parameters with / without change.
P2000 Reference frequency
Full-scale frequency setting used by serial link (corresponds to 4000H), analog I/O and P/D
controller.
Unit: Hz Min: 1.00 Def: 50.00 Max: 650.00
Level 2
P2001 Reference voltage
Full-scale output voltage (i.e. 100% ) used over serial link (corresponds to 4000H).
Unit: V Min: 10 Def: 1000 Max: 2000
Level 3
Example P2001=230 specifies that 4000H received via USS denotes 230 V
P2002 Reference current
Full-scale output current used over serial link (corresponds to 4000H).
Unit: A Min: 0.10 Def: 0.10 Max: 10000.00
Level 3
r2004 Reference power
Full-scale reference power used over the serial link (corresponds to 4000H).
Unit: - Min: - Def: - Max: -
Level 3
P2009[2] USS normalization
Min: 0 Def: 0 Max: 1
Level 3
Settings: 0=Disabled 1=Enabled
Index: P2009[0]: Serial interface COM link P2009[1]: Serial interface BOP link
Note: If enabled, the main setpoint (word 2 in PZD) is not interpreted as 100%=4000H, but as "absolute" instead
(e.g. 4000H=16384 means 163.84 Hz).
PZD: Process data
P2010[2] USS Baud rate
Sets Baud rate for USS communication.
Unit: - Min: 4 Def: 6 Max: 12
Level 3
Settings: 4=2400 Baud
5=4800 Baud
6=9600 Baud
7=19200 Baud
8=38400 Baud
9=57600 Baud
10=76800 Baud
11= 93750 Baud
12=115200 Baud
Index: P2010[0]: Serial interface COM link P2010[1]: Serial interface BOP link
P2011[2] USS address
Sets a unique address for the VSD.
Unit: - Min: 0 Def: 0 Max: 31
Level 3
Index: P2011[0]: Serial interface COM link P2011[1]: Serial interface BOP link
Note: You can connect up to another 30 VSDs via RS-485 (i.e. 31 VSDs in total) and control them with the USS serial bus protocol.
P2014[2] USS telegram off time
Defines a time T_off after which a fault will be generated (F0070) if no telegram is received via
the USS channels.
Unit: ms Min: 0 Def: 0 Max: 65535
Level 3
Index: P2014[0]: Serial interface COM link P2014[1]: Serial interface BOP link
Note: By default (time set to 0), no fault is generated (i.e. watchdog disabled).
P2040 CB telegram off time
Defines time after which a fault will be generated (F0070) if no telegram is received via the link (SOL).
Unit: ms Min: 0 Def: 20 Max: 65535
Level 3
Dependency: Setting 0=watchdog disabled
P2041[5] CB parameter
Configures a communication board (CB)
Unit: - Min: 0 Def: 0 Max: 65535
Level 3
Index: P2041[0]: CB parameter 0
P2041[1]: CB parameter 1
P2041[2]: CB parameter 2
P2041[3]: CB parameter 3
P2041[4]: CB parameter 4
Note: See relevant communication board Manual for protocol definition and appropriate settings.
r2050[8] CO: PZD from CB
Displays PZD (process data) received from the communication board (CB).
Unit: - Min: - Def: - Max: -
Level 3
Index: r2050[0]: Received word 0
r2050[1]: Received word 1
r2050[2]: Received word 2
r2050[3]: Received word 3
r2050[4]: Received word 4
r2050[5]: Received word 5
r2050[6]: Received word 6
r2050[7]: Received word 7
Note: The control words can be viewed as bit parameters r2032 and r2033.
P2051[8] CI: PZD to CB
Connects PZD to CB. This parameter allows the user to define the source of status words and
actual values for the reply PZD. (PZD: Process data).
Level 3
