Siemens SIMATIC ET 200SP Product Information

Supplements to ET 200SP documentation
2.5 I/O module manuals
Product information on the documentation of the ET 200SP distributed I/O system
54 Product Information, 02/2021, A5E03799595-BG
New section in Appendix B: "Measured values for wire break"
Table 2- 4 Measured values at a wire break depending on enabled diagnostics
Programmable diagnos-
tics
Measured value Explanation
Wire break
Underflow
Enable
Enable
32767
7FFF
H
The "wire break" diagnostics is reported, be-
cause this has a higher priority.
Disable
Enable
-32768
8000
H
The "Lower limit violated" diagnostics is report-
ed.
Disable
Disable
-32768
8000H
No diagnostics reported.
AI 2xU/I 2-/4-wire HS analog input module manual, Edition 09/2018
Note
A connection between the current inputs I
n and the reference ground Mn is not allowed and
leads to malfunctions of the module.
Manual AI 4xTC HS, Edition 03/2019
"Parameters" section
Table 2- 5 Configurable parameters and their defaults (GSD file)
Parameters Value range Default Reconfigu-
ration in
RUN
Scope with configuration
software, e.g. STEP 7
(TIA Portal)
GSD file
PROFINET IO
GSD file
PROFIBUS DP
Fixed reference
temperature
0 °C
0 °C
No
Channel
-
"Technical specifications" section
The abbreviation SFU stands for interference frequency suppression.

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
