Siemens SIMATIC ET 200SP Product Information

Supplements to ET 200SP documentation
2.5 I/O module manuals
Product information on the documentation of the ET 200SP distributed I/O system
Product Information, 02/2021, A5E03799595-BG
55
Manual AI Energy Meter 480VAC ST, Edition 12/2015
For configuration with STEP 7 V13 or higher (TIA Portal), real values between -7x10
28
and
+7x10
28
can be input. This is true for configuration via HSP and via GSD file (PROFINET).
For configuration with STEP 7 V5.5 SP4 as of HF7, configuration by means of GSD file
(PROFINET) with REAL values of -1.175x10
38
to +3.402x10
38
is possible.
With STEP 7 SP4 to HF6, parameter assignment of REAL values is not possible. Functions that
require REAL values are not available in this case.
Manuals AI Energy Meter 400VAC ST, Edition 12/2015; AI Energy Meter 480VAC ST, Edition
12/2015
Requirements for the operation of the AI Energy Meter on slot 1 of the ET 200SP:
Interface module / CPU AI Energy Meter 400VAC ST
(6ES7134-6PA01-0BD0)
AI Energy Meter 480VAC ST
(6ES7134-6PA20-0BD0)
IM 155-6 PN BA (6ES7155-6AR00-
0AN0)
Can be operated on slot 1 for all IM 155-6 PN BA
IM 155-6 PN ST (6ES7155-6AU00-
0BN0)
Can be operated on slot 1 for IM 155-6 PN ST from firmware version V3.1 and
higher and functional status FS 07
IM 155-6 PN HF (6ES7155-6AU00-
0CN0)
Can be operated on slot 1 for IM 155-6 PN HF from firmware version V3.0 and
higher and functional status FS 05
IM 155-6 DP HF (6ES7 155-6BU00-
0CN0)
Can be operated on slot 1 for IM 155-6 DP HF from firmware version V3.0 and
higher
CPU 1510SP-1 PN, CPU 1512SP-1 PN,
CPU 1515SP PC
Can be operated on slot 1 for all CPUs
In the manual for Energy Meter 480VAC ST, Edition 12/2015
In the device manual for Energy Meter 480VAC ST, the measured value ID and the associated
measured variables for the complete performance are reversed. The correct association is
shown in the table below:
Measured
value ID
Measured variables Unit
34
Total active power L1L2L3
W
35
Total reactive power L1L2L3
var
36
Total apparent power L1L2L3
VA
65
Max. total active power
W
66
Max. total reactive power
var
67
Max. total apparent power
VA
95
Min. total active power
W
96
Min. total reactive power
var
97
Min. total apparent power
VA

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
