Siemens SIMATIC ET 200SP Product Information

Supplements to ET 200SP documentation
2.5 I/O module manuals
Product information on the documentation of the ET 200SP distributed I/O system
Product Information, 02/2021, A5E03799595-BG
57
Manuals for analog output modules
Manual
Edition
Analog output module AQ 2xI ST
12/2015
Analog output module AQ 2xU/I HF
02/2014
Analog output module AQ 2xU/I HS
09/2016
Analog output module AQ 4xU/I ST
03/2016
"Representation of analog values in the current output ranges" section
Table 2- 6 Current output ranges 4 to 20 mA
Values
Current output range
Range
Dec.
Hex.
4 to 20 mA
118.5149 %
32767
7FFF
21 mA
Overflow*
29377
72C1
106.25 %
29376
72C0
21 mA
Overrange
27649
6C01
20 mA + 578.7 nA
100 %
27648
6C00
20 mA
Rated range
75 %
20736
5100
16 mA
0.003617 %
1
1
4 mA + 578.7 nA
0 %
0
0
4 mA
-1
FFFF
3.9995 mA
Underrange
-2.5 %
-692
FD4C
3.6 mA
-693
FD4B
3.6 mA
Underflow*
-118.519 %
-32768
8000
* Outputs positive maximum value or negative minimum value
Manuals for analog input modules
Manual
Edition
AI 8xI 2/4-wire Basic (6ES7134-6GF00-0AA1)
03/2015
AI 4xU/I 2-wire ST (6ES7134-6HD01-0BA1)
09/2019
AI 2xI 2/4-wire ST (6ES7134-6GB00-0BA1)
04/2018
AI 2xU/I 2-, 4-wire HS (6ES7134-6HB00-0DA1)
09/2018
AI 4xI 2/4-wire ST (6ES7134-6GD01-0BA1)
09/2018
AI 4xRTD/TC 2/3/4-wire HF (6ES7134-6JD00-0CA1)
09/2019
AI 8xRTD/TC 2-wire HF (6ES7134-6JF00-0CA1)
09/2019
AI 4xTC HS (6ES7134-6JD00-0DA1)
03/2019
"Diagnostic messages" section
Diagnostic messages in the measured value of analog input modules
Each analog input module supplies the measured value 7FFF
H or 8000H depending on the
parameter assignment when an error is detected.

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
