11-4
Equipment
Manual OP7, OP17
Release 04/99
The
OP is used to operate and monitor a system for producing and bottling
dif
ferent fruit juices. The system consists basically of a mixing unit and a
bottling machine.
Mixing unit
The ingredients for the fruit juices are contained in three tanks. Depending on
the juice that you wish to manufacture, ingredients are mixed in certain ra
-
tios.
Bottling machine
After it has been mixed, the fruit juice flows into the bottling tank after a
valve has been opened and then bottled in the correct quantities. The bottles
are conveyed on a belt. Before being filled, they are checked for breakages
After they have been filled, the bottles are capped, labeled and transferred to
pallets.
The configured basic screen could look – for example, on the OP7 display –
like the one shown in figure 1
1-2. It consists of static text only
.
Unit 1
Mix Bottle
<< | | >>
Figure 11-2 Start Screen of the System (Example)
The
screen segment on the display can be moved horizontally with the soft
keys below the symbol << and >>.
Pressing the soft key beneath the ”
Mix
” entry allows you to view the entry
shown in figure 1
1-3. It similarly consists only of static text which refers to
other screens (”
Tank2
”, ”
Tank3
” and ”
Mixer”).
Mixer unit
Tank2 Tank3 Mixer
<< | | |
Figure 11-3 Screen with Static Text (Example)
Example
