16-4
Equipment
Manual OP7, OP17
Release 04/99
The
OP17 is available in versions PP
, DP and DP-12. The versions dif
fer only
in as far as their communication options are concerned (refer to table 16-2).
Figure 16-2 shows the connection elements on the lower side of the OP17.
IF 1B IF 1A
IF
2
 

 

Figure 16-2 Locations of the Connection Elements on the Underside of the OP17
Table 16-2 Communications Options Featured by Different OP17 Versions
Connections OP17
PP DP DP-12
SIMATIC
S5
– AS51
1 (TTY)
– F
AP (TTY/RS232)
– PROFIBUS-DP up to 1.5 MBd
– PROFIBUS-DP up to 12 MBd
IF 1A
IF 1A
IF 1B
IF 1B
IF 1B
IF 1B
IF 1B
SIMA
TIC S7/M7
– PPI
– MPI
– PROFIBUS-DP up to 1.5 MBd
– PROFIBUS-DP up to 12 MBaud
IF 1B
IF 1B
IF 1B
IF 1B
IF 1B
IF 1B
IF 1B
SIMA
TIC 500/505
– RS232
– RS422/RS485
IF 1A
IF 1B
IF 1A
IF 1B
Other PLCs
– RS232/TTY
– RS422/RS485
IF 1A
IF 1B
IF 1A
IF 1B
PC/PU (TTY/RS232)
IF 2 IF 2 IF 2
Printer (TTY/RS232)
IF 2 IF 2 IF 2
Connection
elements
