16-3
Equipment
Manual OP7, OP17
Release 04/99
16.2 OP17

230
194
204
 
 
 
240

132
The
OP17 requires the following mounting cutout (WxH):
231
+1
mm x 195
+1
mm.
Dimensions
Mounting cutout
