B-15
Equipment Manual OP7, OP17
Release 04/99
Remedy:CauseMes-
sage
685 Configuration error. T wo tags that supply infor -
mation about the faulty function (T ag 1) and the
faulty parameter (T ag 2) are transferred together
with this message.
Variable 1:
535 Conversion, Linear 1
536 Conversion, Linear 2
537 Increment, variable
539 Increment current
545 Convert value
Variable 2:
This specifies the parameter of the function in
which an error has arisen (e.g. T ag 2 = 3: parame -
ter 3 of the T ag 1 function is faulty).
If you are dealing with a configura -
tion error: delete the function and re -
configure.
Or if the OP tries to determine the
value of a tag while no PLC is con -
nected: connect a PLC.
686 T oo many variables.
701 Internal err or
Incorrect assignment of “head –> res“ when re -
ceiving variable.
702 Job can not be executed. Change interface or configure area
pointer.
703 Flash memory full. Restrict the configuration.
704 Incorrect CPU specified under ”PLC –> Parame -
ters”.
Change configuration and retransfer .
705 An acknowledged message can not be entered in
the buf fer because the corresponding message or
a message in the same acknowledgement group is
missing.
706 Recipe request will not be processed as another
request is already active.
707 Internal err or
S7 message task error .
708 Internal err or
Incorrect mailbox type
709 Internal err or
Invalid mailbox type.
710 Internal err or
Incorrect mode.
711 Internal err or
Display status invalid.
712 No submenu configured.
713 Internal err or
No special operator object configured.
