SIMATIC IPC277E 9" MT
A5E44033779-AA, 3/2018
7
1.2
Design
Front and side views
①
Cutout for mounting clips
②
Display/touch screen
③
Mounting seal
Bottom view
①
Cutout for mounting clips
②
Interfaces and operating elements
③
Flap for memory card slot
2
Installing and connecting the device
2.1
Secure with mounting clips
Positions of the mounting clips
To achieve the degree of protection for the HMI device, the positions for the mounting clips shown below must be adhered to.
The positions of the mounting clips are marked by stamps on the cutouts. Fit the mounting clips in all the stamped cutouts.
The following table shows the type, number and position of the mounting clips needed (see also section "Design (Page 7)"):
HMI device
Mounting clips
Type
Quantity
Position on the HMI device
9" display 10
