Technical specifications
Certificates and approvals
Approvals
Note
The following overview shows possible approvals.
The HMI device itself is approved as shown on the rear panel labels.
The device meets the guidelines listed in the following sections.
EU Declaration of Conformity
The associated declaration of conformity is available on the Internet at the following address: Panel PC certificates
(http://support.automation.siemens.com/WW/view/en/10805572/134200
).
ISO 9001 certificate
The Siemens quality management system for our entire product creation process (development, production and sales) meets
the requirements of ISO 9001:2008.
This has been certified by DQS (the German society for the certification of quality management systems).
Certificate no.: 001323 QM08
Software license agreements
If the device is supplied with preinstalled software, you must observe the corresponding license agreements.
UL approval
In preparation (recognized):
• Underwriters Laboratories (UL) according to standard UL 61010-2-201 (PROG.CNTLR.) Second Edition, File E85972
• Canadian National Standard CAN/CSA-C22.2 No. 61010-2-201 Second Edition
Technical specifications
Device
IPC477E 22"
frameless
IPC477E 24"
frameless
Safety
Approvals
See rating plate
Overvoltage category
II for all UN
Electrical data
Rated voltage
Permitted voltage range
24 V DC
+19.2 V to +28.8 V
Mechanical data (without packing)
Width
522 mm
578 mm
Height
324 mm
356 mm
Depth
81 mm
81 mm
Weight
7.88 kg
9.02 kg
