Commissioning a project
6.4 Transfer
KTP400 Basic, KTP600 Basic, KTP1000 Basic, TP1500 Basic
64 Operating Instructions, 08/2008, A5E01075587-01
Procedure
Proceed as follows:
1. On the configuration PC, select the "Transfer settings" command from the "Project >
Transfer" menu in WinCC flexible.
The "Select devices for transfer" dialog opens.
2. Select the HMI device in the left area of the dialog.
3. Select the type of interconnection for the HMI device and the configuration PC.
Set the connection parameters.
4. Set the transfer parameters in the right area of the dialog.
5. Start the transfer in WinCC flexible by selecting "Transfer".
The configuration PC checks the connection to the HMI device. The project is transferred
to the HMI device. An error message is displayed on the configuration PC if the
connection is either not available, or disrupted.
Result
The project is available on the HMI device after successful completion of the transfer. The
transferred project is started automatically.
6.4.3 Starting automatic transfer
Introduction
If automatic transfer is activated, the HMI device automatically changes to "Transfer" mode
at runtime as soon as a transfer is started on the connected configuration PC.
Note
With automatic transfer, the HMI device only changes into "Transfer" mode when the project
is running on the HMI device.
Automatic transfer is particularly suited for the test phase of a new project since transfer is
completed without interfering with the HMI device.
