Configuring the operating system
6.2 Calibrating the touch screen
MP 377 15" Touch daylight readable (WinCC flexible)
Operating Instructions (Compact), 04/2009, A5E02532357-01
41
3. Touch the "Confirm" button.
3OHDVHSUHVVWKHEXWWRQWRFRQILUPFDOLEUDWLRQ
&RQILUP
The calibration is saved. The "OP Properties" dialog, "Touch" tab is displayed again. If
you do not touch the "Confirm" button within 5 s, your original calibration will be retained.
4. Close the dialog.
Result
The HMI device touch screen is calibrated.
