Assembly and disassembly
5.5 DIN rail mounting
SCALANCE WxM766
Operating Instructions, 03/2022, C79000-G8976-C617-03
47
4. Connect the power supply, refer to the section "Power supply".
5. Fit the antennas, refer to the section "Antennas".
Uninstalling
1. Turn off the power to the device.
2. Disconnect all connected cables.
3. Pull the DIN rail slider down with a screwdriver
.
4. Tilt the device forward
and remove the device from the DIN rail.
5. Loosen the screws completely.
