7.5 Technical specifications of the SCALANCE XC216
The following technical specifications apply to the SCALANCE XC216.
Technical specifications
Attachment to Industrial Ethernet
Electrical connectors Quantity 16
Connector RJ-45 jack
Properties Half/full duplex, MDI‑X pinning
Transmission speed 10 / 100 Mbps
Diagnostics interface
Serial interface
Quantity 1
Connector RJ-11 jack
Electrical data
Power supply
1)
Rated voltage 12 to 24 VDC
Voltage range (incl. tolerance) 9.6 to 31.2 VDC Safe Extra Low Voltage
(SELV)
Design Terminal block, 4 terminals
Properties Implemented redundantly
Current consumption 12 VDC 550 mA
24 VDC 275 mA
Effective power loss 6.6 W
Overvoltage category CAT II
Fusing 2.5 A / 125 V
Signaling contact
1)
Quantity 1
Design Terminal block, 2 terminals
Permitted voltage range 24 VDC
Load capability max. 100 mA
Permitted ambient conditions
Ambient temperature During operation up to 2000 m -40 °C to +70 °C
During storage -40 ℃ to +85 ℃
During transportation -40 ℃ to +85 ℃
Relative humidity During operation at 25 ℃ ≤ 95 % no condensation
Housing, dimensions and weight
Design compact
Housing material Basic housing Die cast aluminum, powder coated
Front cover Polycarbonate (PC-GF10)
Degree of protection IP20
Dimensions (W x H x D) 120 x 145 x 125 mm
Weight 800 g
Technical specifications
7.5 Technical specifications of the SCALANCE XC216
SCALANCE XC-200
Operating Instructions, 12/2017, C79000-G8976-C442-03 65
