Technical specifications
Housing, dimensions and weight
Design compact
Housing material Basic housing Die cast aluminum, powder coated
Front cover Polycarbonate (PC-GF10)
Degree of protection IP20
Dimensions (W x H x D) 120 x 145 x 125 mm
Weight 880 g
Installation options
● Wall mounting
● Installation on a DIN rail
● Mounting on an S7-300 standard rail
● Mounting on an S7-1500 standard rail
Mean time between failure (MTBF)
MTBF (EN/IEC 61709; 40 °C) > 41 years
1)
Note the wiring rules (Page 51).
7.7 Mechanical stability (in operation)
Mechanical stability (in operation)
Device IEC 60068-2-27 shock IEC 60068-2-6 vibration
15 g, 11 ms duration
6 shocks per axis
10 - 58 Hz: 0.075 mm
85 - 150 Hz: 1 g
1 octave/min, 20 sweeps
SCALANCE XC206-2 (ST/BFOC) ● ●
SCALANCE XC206-2 (SC) ● ●
SCALANCE XC206-2SFP ● ●
SCALANCE XC208 ● ●
SCALANCE XC216 ● ●
SCALANCE XC224 ● ●
7.8 Cable lengths
The cable lengths listed below apply to the SCALANCE XC-200.
Cable Permitted cable length
IE TP torsion cable
with IE FC Outlet RJ-45 + 10 m TP cord
0 to 45 m
+ 10 m TP cord
IE TP torsion cable
with IE FC RJ-45 Plug 180
0 to 55 m
Technical specifications
7.8 Cable lengths
SCALANCE XC-200
Operating Instructions, 12/2017, C79000-G8976-C442-03 67
