Side view of the SCALANCE XC-200
① Securing bar in the rail mounting position
② Securing bar in the wall mounting position (as supplied).
Figure 8-3 Depth
Dimension drawings
8.1 Dimension drawings SCALANCE XC-200
SCALANCE XC-200
Operating Instructions, 12/2017, C79000-G8976-C442-03 71
