Description of the device
3
3.1 Product overview
Article numbers
Device Description Article number
SCALANCE XC206-2 (ST/
BFOC)
6 x 10/100 Mbps RJ-45 ports, 2 x 100 Mbps ST/BFOC ports,
multimode FO cable
6GK5 206-2BB00-2AC2
SCALANCE XC206-2 (SC) 6 x 10/100 Mbps RJ-45 ports, 2 x 100 Mbps SC ports, multimode
FO cable
6GK5 206-2BD00-2AC2
SCALANCE XC206-2SFP 6 x 10/100 Mbps RJ-45 ports, 2 x pluggable transceiver slots
with 100/1000 Mbps
6GK5 206-2BS00-2AC2
SCALANCE XC208 8 x 10/100 Mbps RJ-45 ports 6GK5 208-0BA00-2AC2
SCALANCE XC216 16 x 10/100 Mbps RJ-45 ports 6GK5 216-0BA00-2AC2
SCALANCE XC224 24 x 10/100 Mbps RJ-45 ports 6GK5 224-0BA00-2AC2
Factory settings
● Industrial Ethernet protocol: PROFINET
● Base Bridge mode: 802.1D transparent bridge
● Redundancy mechanism: Ring redundancy
Device Factory setting ring ports
SCALANCE XC206-2 (ST/BFOC) and XC206-2 (SC) P0.7 and P0.8
SCALANCE XC206-2SFP, XC208, XC216 and XC224 P0.1 and P0.2
● Trust mode: Trust COS
Type designation
The type designation of a SCALANCE XC-200 is made up of several parts that have the
following meaning:
[ - ]
SFP
Number of electrical connectors
Number of optical connectors
XC2 -
SCALANCE XC-200
Operating Instructions, 12/2017, C79000-G8976-C442-03 17
