Technical specifications
Degree of protection IP20
Dimensions (W x H x D) 60 x 145 x 125 mm
Weight 540 g
Installation options
● Wall mounting
● Installation on a DIN rail
● Mounting on an S7-300 standard rail
● Mounting on an S7-1500 standard rail
Mean time between failure (MTBF)
MTBF (EN/IEC 61709; 40 °C) > 46 years
1)
Note the wiring rules (Page 51).
7.3 Technical specifications SCALANCE XC206-2SFP
The following technical specifications apply to the SCALANCE XC206-2SFP.
Technical specifications
Attachment to Industrial Ethernet
Electrical connectors Quantity 6
Connector RJ-45 jack
Properties Half/full duplex, MDI‑X pinning
Transmission speed 10 / 100 Mbps
Slots for pluggable transceivers Quantity 2
Connector SFP transceivers (LC port)
Transmission speed 100 / 1000 Mbps
Diagnostics interface
Serial interface
Quantity 1
Connector RJ-11 jack
Electrical data
Power supply
1)
Rated voltage 12 to 24 VDC
Voltage range (incl. tolerance) 9.6 to 31.2 VDC Safe Extra Low Voltage
(SELV)
Design Terminal block, 4 terminals
Properties Implemented redundantly
Current consumption 12 VDC Without SFP 400 mA
With SFP
2)
500 mA
24 VDC Without SFP 200 mA
With SFP
2)
250 mA
Effective power loss Without SFP 4.8 W
With SFP
2)
6 W
Overvoltage category CAT II
Fusing 2.5 A / 125 V
Technical specifications
7.3 Technical specifications SCALANCE XC206-2SFP
SCALANCE XC-200
62 Operating Instructions, 12/2017, C79000-G8976-C442-03
