Technical specifications
Optical connectors Quantity 2
Connector SC socket
Properties Full duplex acc. to 100Base-FX
Transmission speed 100 Mbps
Cable type Multimode glass FO cable
Transmitter output (optical)
● Minimum
● Maximum
● -19 dBm
● -14 dBm
Receiver input
● Sensitivity min.
● Input power max.
● -32 dBm
● -3 dBm
Cable cross-section
● 50/125 μm
● 62.5/125 μm
Cable length
● 0 ... 5 km
● 0 ... 5 km
Attenuation
● ≤ 1 dB/km at 1310 nm; 1200 MHz * km
● ≤ 1 dB/km at 1310 nm; 1200 MHz * km
Diagnostics interface
Serial interface
Quantity 1
Connector RJ-11 jack
Electrical data
Power supply
1)
Rated voltage 12 to 24 VDC
Voltage range (incl. tolerance) 9.6 to 31.2 VDC Safe Extra Low Voltage
(SELV)
Design Terminal block, 4 terminals
Properties Implemented redundantly
Current consumption 12 VDC 500 mA
24 VDC 250 mA
Effective power loss 6 W
Overvoltage category CAT II
Fusing 2.5 A / 125 V
Signaling contact
1)
Quantity 1
Design Terminal block, 2 terminals
Permitted voltage range 24 VDC
Load capability max. 100 mA
Permitted ambient conditions
Ambient temperature During operation up to 2000 m -40 °C to +70 °C
During storage -40 ℃ to +85 ℃
During transportation -40 ℃ to +85 ℃
Relative humidity During operation at 25 ℃ ≤ 95 % no condensation
Housing, dimensions and weight
Design compact
Housing material Basic housing Die cast aluminum, powder coated
Front cover Polycarbonate (PC-GF10)
Technical specifications
7.2 Technical specifications SCALANCE XC206-2 (SC)
SCALANCE XC-200
Operating Instructions, 12/2017, C79000-G8976-C442-03 61
