Technical specifications
Serial interface
Quantity 1
Connector RJ-11 jack
Electrical data
Power supply
1)
Rated voltage 12 to 24 VDC
Voltage range (incl. tolerance) 9.6 to 31.2 VDC Safe Extra Low Voltage
(SELV)
Design Terminal block, 4 terminals
Property Implemented redundantly
Current consumption 12 VDC 350 mA
24 VDC 175 mA
Effective power loss 4.2 W
Overvoltage category CAT II
Fusing 2.5 A / 125 V
Signaling contact
1)
Quantity 1
Design Terminal block, 2 terminals
Permitted voltage range 24 VDC
Load capability max. 100 mA
Permitted ambient conditions
Ambient temperature During operation up to 2000 m -40 °C to +70 °C
During storage -40 ℃ to +85 ℃
During transportation -40 ℃ to +85 ℃
Relative humidity During operation at 25 ℃ ≤ 95 % no condensation
Housing, dimensions and weight
Design compact
Housing material Basic housing Die cast aluminum, powder coated
Front cover Polycarbonate (PC-GF10)
Degree of protection IP20
Dimensions (W x H x D) 60 x 145 x 125 mm
Weight 520 g
Installation options
● Wall mounting
● Installation on a DIN rail
● Mounting on an S7-300 standard rail
● Mounting on an S7-1500 standard rail
Mean time between failure (MTBF)
MTBF (EN/IEC 61709; 40 °C) > 48 years
1)
Note the wiring rules (Page 51).
Technical specifications
7.4 Technical specifications of the SCALANCE XC208
SCALANCE XC-200
64 Operating Instructions, 12/2017, C79000-G8976-C442-03
