Installation, connecting up, commissioning
3.3 Note on operation
CP 1243-1
32 Operating Instructions, 12/2016, C79000-G8976-C365-02
Requirement: Configuration prior to commissioning
One requirement for the commissioning of the module is the completeness of the STEP 7
project data (see below, step 5).
Installing, connecting up and commissioning the module
Note
Connection with power off
Only wire up the S7
-1200 with the power turned off.
Table 3- 2 Procedure for installation and connecting up
Mount the CP on the DIN rail and connect it to
the module to its right.
Use a 35 mm DIN rail.
The slots to the left of the CPU are permitted.
Connect the Ethernet cable to the CP. You will find the pinout of the interface in the section Technical
Turn on the power supply.
The remaining steps in commissioning involve
downloading the STEP 7 project data.
The STEP 7 project data of the CP is transferred when you
load to the station. To load the station, connect the engineer-
ing station on which the project data is located to the Ethernet
interface of the CPU.
You will find more detailed information on loading in the follow-
ing sections of the STEP 7 information system:
• "Loading project data"
• "Using online and diagnostics functions"
Close the front covers of the module and keep
them closed during operation.
To ensure interference-free operation, keep the front panels of the module closed during
operation.
