Working with the PC Adapter USB
PC Adapter USB
A5E01134250-01
5-3
5.4 Connecting the PC Adapter USB
Connecting to the PC
1. Insert the supplied USB cable into the USB port of your PC.
2. Plug the other end of the USB cable into PC Adapter USB.
Connecting to the PLC
1. Insert the supplied MPI cable into the PC Adapter USB and screw-tighten it.
2. Insert the other end of the MPI cable into the MPI port of your CPU and screw-
tighten it.
Note
The adapter and the S7/M7/C7 system each represent a network node.
• In networks consisting of two nodes (adapter and S7/M7/C7 system), the
adapter is connected directly to the socket of the S7/M7/C7 system.
• When the network contains more than two nodes, the adapter should be
connected to the "PG socket“ of a PROFIBUS connector (SINEC L2 bus
connector). You do not need to change the settings of the terminating resistors.
Caution
Do not connect the SIMATIC PC Adapter USB to the automation system with any
other cable than the supplied MPI cable.
