PC Adapter USB on the MPI/DP Network
PC Adapter USB
6-2 A5E01134250-01
6.3 Use in a networked system
The following illustration shows the connection in a networked S7 system (MPI/DP
network containing 2 or more network nodes).
S7x
S7y
PROFIBUS bus cable
Adapter
4
)
3
)
4) PROFIBUS bus connector
3)
Bus connector with PG socket
Once you have completed the installation and configuration of the PG / PC
interface, you can communicate with the PLC using your SIMATIC software
package..
