1.3 Components used
This application example was created with these hardware and software
components:
Table 1-1
Components
Quanti
ty
Item number
Note
Power supply
PM1207
1
6EP1332-1SH71
24 Volt for S7-1200
CPU 1214C
DC/DC/DC
1
6ES7214-1AG40-0XB0
A different S7-1200
CPU from the
SIMATIC product
range can also be
used as an
alternative.
Communication module
CM1241 RS232
1
6ES7241-1AH32-0XB0
Version 2.1 onward
SIMATIC RF1070R reader
1
6GT2831-6BA50
Alternatively, a
SIMATIC RF1040R
reader can also be
used
(6GT2831-6CA50).
RF1000 connection cable
with open ends for
communication via the
RS232 port
1
6GT2891-2UH30
-
LOGO!POWER/1AC/
DC5V/3A
1
6EP3310-6SB00-0AY0
5 Volt for RF1070R
STEP 7 V16 Professional
1
6ES7822-1AA06-0YA5
-
Note
This description also applies to the STEP 7 V15.1 project that you can find on
the same Siemens Industry Online Support page, \2\.
This Application Example consists of the following components:
Table 1-2
Components
File name
Note
Project
"109780625_RF1070R_CM1241_Read
UID_PROJ_V16_V10.zip"
This zipped file contains the
V16 project.
Documentation
"109780625_RF1070R_CM1241_Read
UID_DOCU_V10.pdf"
This description also applies
to the STEP 7 V15.1 project.
