5.1.3 System jobs
The following describes the jobs that are implemented in this example. Note that
you must wait for the respective response telegram (reader response time) before
you can send new request telegrams.
syscmd_reset: Reset the SIMATIC RF1070R reader
Table 5-1 job telegram
Byte
Value
Description
0
0x0C
Without checksum
0x1C
With checksum
1
0x00
DevCode of the command set containing the command to be called.
2
0xC3
CmdCode of the command to be called.
3…4
0x00
Parameter length (0 bytes)
5
0xC2
Optional checksum (when the value "0x1C" is set in byte 0).
Table 5-2 response telegram with no errors
Byte
Value
Description
0
0x0C
Without checksum
0x1C
With checksum
1
0x00
DevCode of the command set containing the command to be called.
2
0xC3
CmdCode of the command to be called.
3…4
0x00
Parameter length
5
0xC2
Optional checksum (when the value "0x1C" is set in byte 0).
syscmd_set_port: Setting the SIMATIC RF1070R reader's LED
Table 5-3 Job telegram
Byte
Value
Description
0
0x0C
Without checksum
0x1C
With checksum
1
0x00
DevCode of the command set containing the command to be called.
2
0x07
CmdCode of the command to be called.
3
0x02
Parameter length
4
0x00
5
0x00
port_msk:
• 0x00: LED and acoustic signal transducer
• 0x01: LED lit green
• 0x02: LED lit red
• 0x03: LED lit orange
• 0x04: Acoustic signal transducer
• 0x05: Acoustic signal transducer and LED lit green
• 0x06: Acoustic signal transducer and LED lit red
• 0x07: Acoustic signal transducer and LED lit orange
6
0xXX
