"SIMATIC Mobile Reader" app
5.5 "Settings" menu
Mobile reader SIMATIC RF660M
50 Operating Instructions, 02/2022, C79000-G8976-C660-01
Functions of the menu
Table 5- 8 Functions of the "Locate" menu
Functions/
Description
Starts with ...
Option buttons for the match conditions of the EPC ID:
• Exact match: Specification that the EPC ID of the detected transponder has to
match that of the selected transponder exactly.
• Starts with...: Specification that only part of the EPC ID of the detected
transponder has to match that of the selected transponder.
When searching for multiple transponders with the "Starts with ..." option,
note that you can only remove digits starting from the end of the EPC ID.
Input box to adapt the EPC ID.
Button to start the localization process
5.5 "Settings" menu
In the menu "Settings", you can configure the "SIMATIC Mobile Reader for RFID" app.
This menu is divided into the following tabs:
• Radio
• Logbook
• Update
• Other
• Info
