Transponder
7.10 SIMATIC RF625T
SIMATIC RF600
398 System Manual, 11/2018, J31069-D0171-U001-A21-7618
7.10.5 Dimension drawing
Figure 7-25 SIMATIC RF625T UHF Disk Tag
Units of measurement: All dimensions in mm
7.10.6 Certificates and approvals
Table 7- 38 6GT2810-2EE00 - RF625T
Conformity with the RED directive 2014/53/EU
Conformity with the RoHS directive 2011/65/EU
Table 7- 39 6GT2810-2EE01 - RF625T
Federal Communica-
Passive labels or transponders comply with the valid regulations; certifica-
tion is not required
This product is UL-certified for the USA and Canada.
It meets the following safety standard(s):
• UL508 - Industrial Control Equipment
• CSA C22.2 No. 142 - Process Control Equipment
• UL Report E 120869
