Getting started
Easy Book
Manual, 05/2009, A5E02486774-01
27
Adding an HMI device to the project
Adding an HMI device to your project
is easy!
1. Double-click the "Add new device"
icon.
2. Click the "SIMATIC HMI" buttonin
the Add new device" dialog.
3. Select the specific HMI device from
the list.
You can choose to run the HMI
wizard to help you configure the
screens for the HMI device.
4. Click "OK" to add the HMI device to
your project.
The HMI device is added to the project.
STEP 7 Basic provides an HMI wizard that helps you
configure all of the screens and structure for your HMI
device.
If you do not run the HMI wizard, STEP 7 Basic
creates a simple default HMI screen.
