4 Configuration and Project Engineering
4.1 Creating the project configuration
SINAMICS G120 as a Speed Axis on the S7-1500
V1.0a, Entry ID: 78788716
Copyright Siemens AG 2013 All rights reserved
No. Action Picture
12. In the “Devices & networks”
editor, go to the Properties of
the SINAMICS drive.
1. Select “Device view”
2. Select the drive
3. Click on “Properties”.
13. When using a SINAMICS
G120 with PROFINET:
In
>PROFINET interface
>Ethernet addresses,
check the IP address of the
SINAMICS drive.
(PROFIBUS on the next
page)
When using a SINAMICS
G120 with PROFIBUS:
In
>PROFIBUS address,
check the address of the
SINAMICS drive.
