Technology functions
3.2 Pulse generators
CPU 1512C-1 PN (6ES7512-1CK00-0AB0)
58 Manual, 09/2016, A5E35306440-AB
Category
Parameter
Meaning
Value range
Default
Fine resolu-
tion
Bits in incr. actual
value (G1_XIST1)
The parameter defines the
number of bits for the coding
of the fine resolution in the
current incremental value of
G1_XIST1.
0 0
Stop behav-
ior
Quick stop time The parameter "Quick stop
time" defines the time interval
it should take for the drive to
go from the maximum speed
to a standstill (OFF3).
1 to 65 535 (ms) 1,000 (ms)
Hardware
inputs /
outputs
Reference switch
input
The parameter "Reference
switch input" defines the
hardware input of the refer-
ence switch.
[Input address of the reference
switch DI]
--
Edge selection refer-
ence switch
The parameter "Edge selec-
tion reference switch" defines
the edge type which is to be
detected by the reference
switch.
Rising edge
Rising edge
Falling edge
Measuring input The parameter "Measuring
input" defines the hardware
input of the measuring input.
[Input address of the measuring
input DI]
--
"Drive ready" input The parameter ""Drive ready"
input" defines the hardware
input of the input "Drive
ready".
[Input addresses of the inputs "Drive
ready" DIn]
--
Pulse output A
for "PTO (pulse (A)
and direction (B))"
The parameter "Pulse output
A" defines the hardware
output for PTO signal A.
[Output address DQ for PTO signal
A (output frequency 100 kHz)]
grayed out
Read only
access to the
parameter
Direction output B
for "PTO (pulse (A)
and direction B))"
The parameter "Direction
output B" defines the hard-
ware output for PTO signal B.
[Output address 1 of the DQ for
PTO signal B (output frequency
100 kHz)]
Qn (output
frequency
100 kHz)
[Output address 2 of the DQ for
PTO signal B (output frequency 100
Hz)]
Clock generator
forward (A)
for "PTO (Count up
(A) and Count down
(B))"
The "Clock generator forward
(A)" parameter defines the
hardware output for PTO
signal A.
[Output address DQ for PTO signal
A (output frequency 100 kHz)]
grayed out
Read only
access to the
parameter
Clock generator
backward (B)
for "PTO (Count up
(A) and Count down
(B))"
The "Clock generator back-
ward (B)" parameter defines
the hardware output for PTO
signal B.
[Output address 1 of the DQ for
PTO signal B (output frequency
100 kHz)]
grayed out
Read only
access to the
parameter
Phase A
for "PTO (A, B
phase-shifted)" and
"PTO (A, B phase-
shifted, quadruple)"
The "Clock generator output
(A)" parameter defines the
hardware output for PTO
signal A.
[Output address of the DQ for PTO
signal A (output frequency 100 kHz)]
grayed out
Read only
access to the
parameter
