Siemens SIMATIC S7-1500T - Technology Objects for Counting and Measuring

1 SIMATIC’s Technology Objects
1.3 SIMATIC S7-1500 and SIMATIC S7-1500T
TOs of S7-1500(T)
Entry ID: 109743134, V1.0, 05/2017
9
 Siemens AG 2017 All rights reserved
1.3.3 Technology objects for counting and measuring
Figure 1-3 Technology objects of the S7-1500 – counting and measuring
 High-speed counter (High_Speed_Counter)
The High_Speed_Counter technology object enables the easy configuration of
counter modules for the operation with incremental and pulse encoders and
their use in the user program.
 Measuring/position decoding (SSI_Absolute_Encoder)
The SSI_Absolute_Encoder technology object enables the easy configuration
of position decoding modules for the operation with SSI absolute value
encoders and their use in the user program.
