Ethernet Gateway for SIMATIC MPI/PROFIBUS Driver
GP-Pro EX Device/PLC Connection Manual
4
Connection Configuration
1:1 Connection
1:n Connection
or
Display
External Device
Adapter
Display
External Device
External Device
Adapter
Maximum number of External Devices: 12
Display
External Device
External Device
Adapter
HUB
Maximum number of External Devices: 12
