Ethernet Gateway for SIMATIC MPI/PROFIBUS Driver
GP-Pro EX Device/PLC Connection Manual
5
n:m Connection
or
• It is able to connect only one adapter to one Display.
Display
External Device
Display
External Device
Adapter
Adapter
HUB
Maximum Display Units depends
on the External Device CPU
Maximum number of Display: 12
Display
External Device
Display
External Device
Adapter
HUB
Maximum number of Display: 7 Maximum number of Display: 12
