Preface
SIRIUS Motor Starter PCS 7 Library "V7.1+SP2"/ "V8 Migration V8.0+SP1"
8 Getting Started, 08/2013, A5E02897539020A/RS-AA/005
Software required for the Getting Started of the PCS 7 block library for motor starters
● You can execute the example project on any PC or programming device on which the
following software is installed:
– Windows operating system
– Internet Explorer
– Message Queuing service
– SQL server
Note
The versions required conform to the version of PCS 7 installed.
You can find further relevant details in the following manuals:
– "SIMATIC Process Control System PCS 7 PC Configuration and Authorization"
– "SIMATIC Process Control System PCS 7 V7.0 Released Modules"
– "SIMATIC Process Control System PCS 7 Released Modules (V7.1)"
● You create the PCS 7 project with SIMATIC Manager.
To do so, follow the instructions in the following documentation:
– "SIMATIC PCS 7 Process Control System V7.0 Getting Started - First Steps
Documentation"
– Getting Started: SIRIUS Motor Starter PCS 7 Library "V7.1+SP2"/ "V8 Migration
V8.0+SP1"
You can find this document in
Start > SIMATIC > Documentation > English
Hardware required for creating an example project
Table 1- 1 ET 200S motor starter hardware
Order number Description
6ES7151-1BA02-0AB0 SIMATIC ET 200S distributed I/O IM151-1 HIGH FEATURE
3RK1903-0BA00 PM-D for ET 200S power module for starter 24 V DC
3RK1903-3BA02 PM-D F for ET 200S power module for starter 24 V DC, PROFIsafe
3RK1301-0AB10-0AA4 DS1E-X for ET 200S HIGH FEATURE Direct Starter, setting range 0.3 to 3 A
3RK1301-0AB20-0AA4 DSS1E-X for ET 200S HIGH FEATURE Direct Soft Starter, setting range 0.3 to 3 A
3RK1301-0AB10-1AA4 RS1E-X for ET 200S HIGH FEATURE Reversing Starter, setting range 0.3 to 3 A
3RK1301-0BB00-0AA2 DS1-X for ET 200S STANDARD Electromechanics Line Starter
3RK1301-0AB10-0AB4 DS1e-x HF for ET200S Direct Starter DPV1, setting range 0.3 ... 3 A
3RK1301-0AB20-0AB4 sDSS1e-x HF for ET200S Direct Soft Starter DPV1, setting range 0.3 ... 3 A
3RK1301-0AB10-1AB4 RS1e-x HF for ET200S Reversing Starter DPV1, setting range 0.3 ... 3 A
3RK1301-0AB13-0AA4 F-DS1E-X Fail-Safe Direct Starter HF, setting range 0.3 ... 3 A for PM-D F PROFIsafe
