Preface
SIRIUS Motor Starter PCS 7 Library "V7.1+SP2"/ "V8 Migration V8.0+SP1"
Getting Started, 08/2013, A5E02897539020A/RS-AA/005
9
Creating a PCS 7 project
Create the PCS 7 project with the following hardware for the automation station (AS):
Table 1- 2 Hardware - Automation station 1: Configuration direct on the master system
Order number Description
6ES7416-3XL04-0AB0 SIMATIC S7-400, CPU 416-3 CENTRAL PROCESSING,
e.g. with PROFIBUS DP interface
6ES7407-0KA01-0AA0 SIMATIC S7-400, Power Supply PS 407-10 A, UC 120 / 230 V,
DC 5 V / 10 A
Table 1- 3 Hardware - Automation station 2: Configuration following a Y-link
Order number Description
6ES7654-2PG67-0XC0 SIMATIC PCS 7 AS417-4-2H for H systems
6ES7407-0KR00-0AA0 SIMATIC S7-400, Power Supply PS 407, 10 A for redundant use
6ES7153-2BA82-0XB0 SIMATIC DP, Interface DP/PA Link and ET 200M IM153-2 HIGH
FEATURE for H systems
6ES7197-1LB00-0XA0 SIMATIC S7, Y-coupler for building up a Y-link for redundant
controllers
Note
ET 200pro motor starters
The further procedure for a configuration with ET 200pro motor starters is comparable.
