Siemens Simatic series Getting Started

Description
2.4 Status displays
SIMATIC IPC847C
14 Getting Started, 12/2010, A5E02669190-02
Front status displays
OFF
 No connection
 No data traffic
 PROFIBUS not equipped
Display of the
communication status
to S7 or PROFIBUS
GREEN
 MPI/DP data traffic
OFF
 No connection
 No data traffic
 CP 1616 onboard not
equipped
 CP disabled
 No error, communication
established
 Charging in progress
 CP 1616 driver not installed
 CP in NDIS mode
Flashes slowly
RED
 Link status error
 IO controller: IO device cannot
be addressed
 IO controller: Duplicate IP
address
Flashes rapidly
RED
Exception error: diagnostics via
Web or SNMP is no longer
possible
PN Ι MPI/DP
(optional)
Status display for
CP 1616 onboard
RED
 Diagnostics information
available
 No communication established
OFF WATCHDOG not activated
GREEN WATCHDOG monitoring enabled
WATCHDOG WATCHDOG status
display
RED Monitoring time elapsed
OFF Internal temperature OK TEMP Internal temperature
monitoring
RED Internal temperature critical
OFF Fan speed OK FAN Fan status (only with
active DiagBase or
DiagMonitor software)
RED Fan speed too low
OFF RAID is OK
One RED HDD1, HDD2 or HDD3 not OK
All RED RAID not OK
(for information on locating the
faulty HDD, refer to the RAID
system section)
HDD1 ALARM
HDD2 ALARM
HDD3 ALARM
Hard disk alarm in
conjunction with RAID
and monitoring
software
All flashing RAID is synchronized
All displays are lit Error in early BIOS
Post
All lit CPU startup failure
Error in early POST
* For unique labeling, the LAN interfaces are numbered on the enclosure. The numbering by the
operating system may deviate from this.
