Siemens Simatic series Getting Started

Connection
5.2 Connecting the device to power
SIMATIC IPC847C
26 Getting Started, 12/2010, A5E02669190-02
Connecting
Steps for connecting the device to mains
1
Ensure that the ON/OFF switch ② is in "0"
position (Off) when you plug in the power
cord to avoid unintentional startup of the
device.
2 Plug in the connector of the cooling device
①.
3 Connect the power cable to the socket and
turn on the ON/OFF switch ②.
The yellow power LED (standby) on the front
panel of the PC lights up.



Siemens Simatic series Specifications

General

Processor	Intel Core i3, Core i5, Core i7
Operating System	Windows 10 IoT Enterprise, Linux
Storage	SSD, HDD
Interfaces	Ethernet, USB, RS-232/485
Ports	Ethernet, USB, Serial
Mounting	DIN rail, wall
Protection Class	IP65
Graphics	Integrated Intel HD Graphics
Expansion Slots	PCIe
Power Supply	24V DC or 100-240V AC
Operating Temperature	0°C to 50°C (depending on model)
