Dimension Drawings
4.2 Type of construction IM B5 with separately-driven fan
1PH7/4-148
 Siemens AG, 2004. All rights reserved
Induction Motors, 1PH7 (APH7S) – 05.04 Edition
4.2 Type of construction IM B5 with separately-driven fan
* only for cable outlet, NDE
DE NDE
(434 ) *
20
(250
+2
) *
90 bracket
38
k6
180
j6
4
10
196
80
–0.3
80
+1
411
+5
120
146
136
250
215
+0.5
10
N9
415
70
Signal
Pg 11 Pg 29
Flange size A250 acc. to DIN 42948 Shaft centering DR M12 acc. to DIN 332 Mounting flange and shaft end acc. to DIN 42955–N Type of construction IMB5 Tolerance of the key and keyway acc. to DIN 6885 T1
f Mlfb changed 01.13.1999 Cat
1
A
B
C
D
E F
3 4 5 6 7 8
1 2 3 4
A
B
C
D
E
Sheet No. Sheet qty.
Scale 1:3
Index Memo Date Cont./Chkd.
Date: Contact: Checked: A&D DS A P2 AC2
17.04.1996 Katzenberger
Replacement for
Siemens AG
Dimension drawing Type of construction IMB5
510.30417.03
1
1
1PH7 101 / 103
Sigraph
DESIGN
Material Semi–finished prod./Op.Man.No. Model/item No.
f
Lipot
connection
Fig. 4-13 1PH7101/1PH7103, type of construction IM B5
