Siemens Simodrive 1PH7 User Manual

Motor Description
1.8 Bearing design
1PH7/1-30
 Siemens AG, 2004. All rights reserved
Induction Motors, 1PH7 (APH7S) – 05.04 Edition
Continuous speed n
S1
The max. permissible continuous operating speed n
S1
depends on the bearings
and the shaft height (refer to Table 1-14).
Table 1-14 Assignment, max. speed to shaft height and bearing design
SH
[mm]
Coupling out-drive,
belt out-drive
[RPM]
Belt out-drive with
increased cantilever
force
[RPM]
Increased max.
speed
[RPM]
n
max
1)
n
s1
2)
n
max
1)
n
s1
2)
n
max
1)
n
s1
2)
100 9000 5500 – – 12000 10000
132 8000 4500 – – 10000 8500
160 6500 3700 – – 8000 7000
180 5000 3500 5000 3000 7000
3)
4500
3)
225 4500 3100 4500 2700 5500
3)
3600
3)
Important
If the motor is operated at speeds between n
s1
and n
max
, then a speed duty cycle
is assumed that has time components with low speed and standstill in order that
the lubricant being used can re-generate.
1) Mechanical limiting speed (permissible for 10 min. cycle with: 3 min n
max
, 6 min 2/3 n
max
, 1 min stand-
still)
2) Max. continuous operating speed
3) Only coupling out-drive is permissible
