Siemens Simodrive 1PH7 User Manual

Technical Data and Characteristics
2.2 Power-speed and torque-speed diagrams
1PH7/2-42
 Siemens AG, 2004. All rights reserved
Induction Motors, 1PH7 (APH7S) – 05.04 Edition
Table 2-7 Induction motor 1PH7103-ND-0L
P
N
[kW]
n
N
[RPM]
M
N
[Nm]
I
N
[A]
n
max
[RPM]
T
th
[min]
J
[kgm
2
]
m
[kg]
3.7 1000 35 10 12000 20 0.017 40
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
0 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 11000 12000
S1 (13.0 A)
S6–60% (16.0 A)
S6–40% (18.0 A)
continuous
briefly
0
5
10
15
20
25
30
35
40
45
50
55
0 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 11000 12000
M [Nm] P [kW]
n [RPM]
n [RPM]
S1 (35 Nm, 10.0 A)
S6–60% (43 Nm, 11.5 A)
S6–40% (50 Nm, 13.0 A)
continuous
briefly
Fig. 2-4 1PH7103-ND-0L
