Siemens Simodrive 1PH7 User Manual

Technical Data and Characteristics
2.2 Power-speed and torque-speed diagrams
1PH7/2-44
 Siemens AG, 2004. All rights reserved
Induction Motors, 1PH7 (APH7S) – 05.04 Edition
Table 2-9 Induction motor 1PH7103-NF-0L
P
N
[kW]
n
N
[RPM]
M
N
[Nm]
I
N
[A]
n
max
[RPM]
T
th
[min]
J
[kgm
2
]
m
[kg]
5.5 1500 35 13 12000 20 0.017 40
0
1
2
3
4
5
6
7
8
9
10
0 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 11000 12000
S1 (13.0 A)
S6–60% (16.0 A)
S6–40% (18.0 A)
S6–25% (20.5 A)
continuous
briefly
0
5
10
15
20
25
30
35
40
45
50
55
60
65
0 2000 4000 6000 8000 10000 12000
M [Nm] P [kW]
n [RPM]
n [RPM]
S1 (35 Nm, 13.0 A)
S6–60% (43 Nm, 16.0 A)
S6–40% (49 Nm, 18.0 A)
S6–25% (57 Nm, 20.5 A)
continuous
briefly
Fig. 2-6 1PH7103–NF-0L
