2.2 Power-speed and torque-speed diagrams
1PH7/2-46
 Siemens AG, 2004. All rights reserved
Induction Motors, 1PH7 (APH7S) – 05.04 Edition
Table 2-11 Induction motor 1PH7103-NG-0L
P
N
[kW]
n
N
[RPM]
M
N
[Nm]
I
N
[A]
n
max
[RPM]
T
th
[min]
J
[kgm
2
]
m
[kg]
7 2000 33 17.5 12000 20 0.017 40
0 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 11000 12000
S1 (17.5 A)
S6–60% (20.5 A)
S6–40% (23.5 A)
S6–25% (26.0 A)
0
1
2
3
4
5
6
7
8
9
10
11
12
13
continuous
briefly
0
10
20
30
40
50
60
70
80
0 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 11000 12000
M [Nm] P [kW]
n [RPM]
n [RPM]
S1 (33 Nm, 17.5 A)
S6–60% (41 Nm, 20.5 A)
S6–40% (48 Nm, 23.5 A)
S6–25% (55 Nm, 26.0 A)
continuous
briefly
Fig. 2-8 1PH7103-NG-0L
