2.2 Power-speed and torque-speed diagrams
1PH7/2-59
Siemens AG, 2004. All rights reserved
Induction Motors, 1PH7 (APH7S) – 05.04 Edition
Table 2-24 Induction motor 1PH7133-NF
P
N
[kW]
n
N
[RPM]
M
N
[Nm]
I
N
[A]
n
max
[RPM]
T
th
[min]
J
[kgm
2
]
m
[kg]
15 1500 95 34 8000 30 0.l076 90
0
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
0 1000 2000 3000 4000 5000 6000 7000 8000
S6–25% (56.0 A)
S6–40% (49.0 A)
S6–60% (41.0 A)
S1 (34.0 A)
continuous
briefly
0
20
40
60
80
100
120
140
160
180
200
0 1000 2000 3000 4000 5000 6000 7000 8000
M [Nm] P [kW]
n [RPM]
n [RPM]
S1 (95 Nm, 34.0 A)
S6–60% (118 Nm, 41.0 A)
S6–40% (146 Nm, 49.0 A)
S6–25% (172 Nm, 56.0 A)
continuous
briefly
Fig. 2-21 1PH7133-NF
